Mini Crawer Hydraulic Excavator

Mini crawer hydraulic excavator, small size, powerful, tailless design, small turning radius, boom side swing function, can be convenient to dig corners, telescopic side swing function, suitable for work in narrow areas, low maintenance cost, low fuel consumption, high work efficiency.

Share This Product, Choose Your Platform!

Product Details

Mini crawer hydraulic excavator, small size, powerful, tailless design, small turning radius, boom side swing function, can be convenient to dig corners, telescopic side swing function, suitable for work in narrow areas, low maintenance cost, low fuel consumption, high work efficiency. The weight of the machine is 1800kg, the bucket capacity is 0.04m³, and the engine power meets the Euro 5 emissions. Small excavator is suitable for orchard planting, trenching, backfilling, urban construction and other environmental use.

Diesel gasoline mini excavator parameters:
PROJECT UNIT ME18H
Machine weight kg 1830
Bucket volume m³ 0.04
Engine model   Kubota/Yanmar
Decibels within 1 meter Dba 95
L*W*H mm 3050*1100*1500
Chassis width mm 1330/990-1300
Maximum digging radius mm 3910
Maximum digging height mm 3535
Maximum digging depth mm 2270
Walking speed km/h 2.2/4.3
Swing speed   10″/360°
Pump type   Variable volume pump
Max. discharge flow L/min 64.4
Swing motor type   HVSE 5VS28(reducer)
Grade ability   58°
Hydraulic system   HVSE
Walking motor   AIDI:FTMO1A(reducer)
Electric mini excavator parameters:
PROJECT UNIT ME18E
Machine weight kg 1400
Bucket volume m³ 0.04
Engine model Battery LiFePO4/LiCoMnNiO2
BYD:Lithium battery+BMS 72v/ah 300/450
Working time h 4/6
PMSM motor 72v/Kw 7.5
Peak power Kw 15
Charging time h 4-8
Power consumption Kwh 5.2-5.7
Decibels within 1 meter Dba < 50
L*W*H mm 3575*990/1330*1650
Chassis width mm 1330/990-1300
Maximum digging radius mm 3910
Maximum digging height mm 3535
Maximum digging depth mm 2270
Walking speed km/h 2.2/4.3
Swing speed   9.5″/360°
Pump type   Variable volume pump
Max. discharge flow L/mim 64.4
Swing motor type   Eaton SW2.5K
Grade ability   58°
Hydraulic system   Load sensitive

Applicable Scenarios

Construction

Gardens and orchards

Indoor demolition

Digging trenches

FAQ

A: Operators can control it from a distance, keeping them away from dangerous or unstable areas, which greatly reduces the risk of accidents.

A: Yes! With its compact and flexible design, it can easily enter elevators, indoor areas, or narrow construction zones where larger machines can’t reach.

A: It’s fully electric – no traditional fuel needed. This means zero emissions, quieter operation, and less maintenance.

A: Yes. Its lightweight and compact size make it ideal for working on small platforms or limited load-bearing areas.

A: Absolutely. It’s designed for remote operation in hazardous or hard-to-reach areas, reducing the need for manual intervention.

A:Smaller size, electric drive, and remote operation – making it safer, cleaner, and more flexible for modern construction needs.

Ant Cloud Intelligent Equipment (Shandong) Co., Ltd.
