Product Details
Small excavator machines are compact and highly mobile, making them very suitable for various urban and rural operations such as pipeline excavation, foundation construction, public utilities, and home maintenance. Their compact size and special design allow them to work in environments where larger excavators cannot be deployed.Versatility is the real advantage of small digging machines. Thanks to their associated hydraulic power systems, these machines can be equipped with a variety of auxiliary working tools. For instance, they can mount rollers and flat tampers for trench filling and compaction; attach crushing hammers and hydraulic clamps for lightweight demolition work; mount rotary drilling tools for drilling and fishing hooks for lifting heavy objects; and install finger clamps for cleaning tasks, among others.
| PROJECT | UNIT | ME10H |
| Brand | ANTS | |
| Mechine weight | kg | 930 |
| Bucket voluem | m³ | 0.025 |
| Engine model | Koop192fe/B&S | |
| Decibels within l meter | Dba | 115 |
| L*W*H | mm | 2590*1000*1450 |
| Chassis width | mm | 1000/800-1000 |
| Maximum digging radius | mm | 3100 |
| Maximum digging height | mm | 2600 |
| Maximum digging depth | mm | 1780 |
| Walking speed | km/h | 2.2 |
| Hydraulic flow | L/min | 25 |
| Swing speed | 10″/360° | |
| Climbing angle | 40° | |
| Arm swing | Left85°Right45° |
Applicable Scenarios

Construction

Gardens and orchards

Indoor demolition

Digging trenches
