Electric Crawler Excavator

This machine is an electric fully controlled machine that can be operated remotely in addition to manual control. The machine is equipped with 9 position sensors, which can manage the posture of the machine. It is the parent product of unmanned machine development.

Share This Product, Choose Your Platform!

Product Details

No emissions, low noise, green environmental protection
Optional big arm side swing chassis expansion, suitable for smaller range of work.
Equipped with hydraulic oil air cooled radiator to meet the needs of continuous work.

Electric Crawler Excavator

The electric small crawler excavator has good power and stable balance, can work in different terrain and complex environment, and can achieve 360 degree all-round rotation, and its flexibility is greatly improved. The electric crawler excavator is suitable for all kinds of projects that need to be excavated and transported, and has the characteristics of high efficiency, flexibility and adaptability. The electric crawler excavator is powered by electricity, does not produce exhaust gas and noise, and has less impact on the environment. The belt design enables the electric crawler excavator to adapt to a variety of complex terrains and environments. Electric crawler excavators are usually equipped with advanced control systems, making the operation more convenient and efficient.

PROJECT UNIT MEO5E
Machine weight kg 620
Bucket volume m³ 0.02
Engine model Battery LiFePO4/LiCoMnNio2
BYD:Lithium battery+BMS 72v/ah 148
Working time h 8
PMSM motor 72v/Kw 3.5
Peak power Kw 7
Charging time h 4-8
Power consumption Kwh 1.2-1.4
Decibels within 1 meter Dba < 50
L*W*H mm 1600*640*1350
Chassis width mm 600
Maximum digging radius mm 2760
Maximum digging height mm 2400
Maximum digging depth mm 1200
Walking speed km/h 2.2
Hydraulic flow L/mim 20
Swing speed 10″/360°
Climbing angle 30°

Applicable Scenarios

Construction

Gardens and orchards

Indoor demolition

Digging trenches

FAQ

A: Operators can control it from a distance, keeping them away from dangerous or unstable areas, which greatly reduces the risk of accidents.

A: Yes! With its compact and flexible design, it can easily enter elevators, indoor areas, or narrow construction zones where larger machines can’t reach.

A: It’s fully electric – no traditional fuel needed. This means zero emissions, quieter operation, and less maintenance.

A: Yes. Its lightweight and compact size make it ideal for working on small platforms or limited load-bearing areas.

A: Absolutely. It’s designed for remote operation in hazardous or hard-to-reach areas, reducing the need for manual intervention.

A:Smaller size, electric drive, and remote operation – making it safer, cleaner, and more flexible for modern construction needs.

Ant Cloud Intelligent Equipment (Shandong) Co., Ltd.
