Home Mini Excavator

Home small excavator is designed for landscaping, farmland, municipal engineering, vegetable greenhouses, ditching and digging, using small engine, small size, simple design, easy maintenance.

Share This Product, Choose Your Platform!

Product Details

Home small excavator is designed for landscaping, farmland, municipal engineering, vegetable greenhouses, ditching and digging, using small engine, small size, simple design, easy maintenance.
Diesel/gasoline mini excavator parameters:
PROJECT UNIT ME10H
Mechine weight kg 930
Bucket voluem m³ 0.025
Engine model Koop192fe/B&S
Decibels within l meter Dba 115
L*W*H mm 2590*1000*1450
Chassis width mm 1000/800-1000
Maximum digging radius mm 3100
Maximum digging height mm 2600
Maximum digging depth mm 1780
Walking speed km/h 2.2
Hydraulic flow L/min 25
Swing speed 10″/360°
Climbing angle 40°
Arm swing Left85°Right45°
Electric mini excavator parameters:
PROJECT UNIT ME10E
Machine weight kg 950
Bucket volume m³ 0.025
Engine model Battery LiFePO4/LiCoMnNiO2
BYD:Lithium battery+BMS 72v/ah 160/180/210
Working time h 7/8.5/10
PMSM motor 72v/Kw 4.5
Peak power Kw 9
Charging time h 4-8
Power consumption Kwh 1.2-1.5
Decibels within 1 meter Dba < 50
L*W*H mm 2590*1000*1450
Chassis width mm 1000/800-1000
Maximum digging radius mm 3100
Maximum digging height mm 2600
Maximum digging depth mm 1780
Walking speed km/h 3
Hydraulic flow L/mim 27
Swing speed   10″/360°
Climbing angle   45°

Applicable Scenarios

Construction

Gardens and orchards

Indoor demolition

Digging trenches

FAQ

A: Operators can control it from a distance, keeping them away from dangerous or unstable areas, which greatly reduces the risk of accidents.

A: Yes! With its compact and flexible design, it can easily enter elevators, indoor areas, or narrow construction zones where larger machines can’t reach.

A: It’s fully electric – no traditional fuel needed. This means zero emissions, quieter operation, and less maintenance.

A: Yes. Its lightweight and compact size make it ideal for working on small platforms or limited load-bearing areas.

A: Absolutely. It’s designed for remote operation in hazardous or hard-to-reach areas, reducing the need for manual intervention.

A:Smaller size, electric drive, and remote operation – making it safer, cleaner, and more flexible for modern construction needs.
