Mini Bagger 1 Ton

1.Widen the body, width 1 meter, the body is more stable. 2.Equipped with well-known brand engine, powerful power. 3.Increase the hydraulic tank, split design, more conducive to heat dissipation.

Share This Product, Choose Your Platform!

Product Details

1. Widen the body, width 1 meter, the body is more stable.

2. Equipped with well-known brand engine, powerful power.

3. Increase the hydraulic tank, split design, more conducive to heat dissipation.

4. Optional gasoline/diesel/electric power, optional bucket size.

5. Thickened dozer for more stable support.

Advantages of Mini Bagger 1 Ton

  • Small excavators are simple to operate and easy to learn.
  • The use of the side swing function can reduce the difficulty of the excavator operator’s work, especially when operating in a small space. Because operators can more flexibly adjust the attitude and position of the excavator, they can complete the task more easily.
  • The double-layer box structure makes the dozer can withstand greater load and impact force, and improves the stability and service life of the dozer.
  • Natural rubber track, more wear resistant.Natural rubber tracks provide better adhesion and traction, improving the efficiency and safety of the equipment.
PROJECT UNIT ME10H
Mechine weight kg 930
Bucket voluem m³ 0.025
Engine model   Koop192fe/B&S
Decibels within l meter Dba 115
L*W*H mm 2590*1000*1450
Chassis width mm 1000/800-1000
Maximum digging radius mm 3100
Maximum digging height mm 2600
Maximum digging depth mm 1780
Walking speed km/h 2.2
Hydraulic flow L/min 25
Swing speed   10″/360°
Climbing angle   40°
Arm swing   Left85°Right45°

Applicable Scenarios

Construction

Gardens and orchards

Indoor demolition

Digging trenches

FAQ

A: Operators can control it from a distance, keeping them away from dangerous or unstable areas, which greatly reduces the risk of accidents.

A: Yes! With its compact and flexible design, it can easily enter elevators, indoor areas, or narrow construction zones where larger machines can’t reach.

A: It’s fully electric – no traditional fuel needed. This means zero emissions, quieter operation, and less maintenance.

A: Yes. Its lightweight and compact size make it ideal for working on small platforms or limited load-bearing areas.

A: Absolutely. It’s designed for remote operation in hazardous or hard-to-reach areas, reducing the need for manual intervention.

A:Smaller size, electric drive, and remote operation – making it safer, cleaner, and more flexible for modern construction needs.
